1565804-2 Tyco 8 pin terminal assembly connector automotive male connector
Short Description:
Model number:1565804-2
Brand:TE
Number of rows: 2
Circuit application: Signal
Number of circuits: 8
Body material: PBT
Type:Housing
Application:Automotive
Material:PA66
Color:Natural
TH/025 Connector System, Housing for Male Terminals, Wire-to-Wire,8Position,.087 in [2.2 mm] Centerline, Natural, Signal
Product Detail
VEDIO
Product Tags
TE Connectivity 1565804-2 Automotive Connector，8-Position Wire-to-Wire Terminal Assembly for Vehicle Electrical Systems。
Core SpecificationsParameter
Manufacturer：TE Connectivity (Tyco)
Position Count ：8-pin Receptacle (Female)
Pitch：2.2 mm [.087 in]
Termination：Crimp Style
Voltage Rating ：12 VDC
Temperature Range：-30°C to +105°C
Housing Material：Polybutylene Terephthalate (PBT)
Dimensions：33.9(L) × 14.2(W) × 14.7(H) mm
Weight：3.060 g
Certification：RoHS Compliant
Data Overview
| Connector & Housing Type | Housing for Male Terminals |
| Number of Positions | 8 |
| Sealable : | No |
| Operating Temperature Range | -30 – 105 °C [ -22 – 221 °F ] |
| Number of Rows | 2 |
Contact Features
| Connector Shape | Rectangular |
| Mixed & Hybrid Connector | No |
| Primary Locking Feature | Integrated in Housing |
| Connector System | Wire-to-Wire |
| Connector & Contact Terminates To | Wire & Cable |
