180437-2 TE Connectivity FASTON .110″ Quick Disconnect Receptacle
Short Description:
Quick Disconnect Receptacle
Uninsulated
20 – 15 AWG
.51 – 1.65 mm² Wire
2.8 mm [.11 in] Tab Width
F-Crimp
Straight
Brass
FASTON 110
Product Detail
Product Tags
TE Connectivity180437-2 is a high-performance female quick-disconnect receptacle from the FASTON .110" series, designed for efficient and reliable electrical connections in low-voltage applications.
Key Features & Specifications
Tab Compatibility: Matches .110" (2.79–2.8mm) wide male tabs, with a thickness range of 0.5mm
Wire Range: Supports 20–16 AWG (0.5–1.5 mm²) conductors, ideal for F-crimp or barrel crimp installations
Material: Tin-plated brass contacts for superior conductivity and corrosion resistance
Voltage: Up to 300V AC/DC.
Current: 10A continuous (varies by wire gauge and environmental conditions)
Certification: UL 1977 recognized for component safety
Data Overview
| Quick Disconnect Terminal Type | Receptacle |
| Wire Size (AWG) | 20 – 15 |
| Wire Size (mm²) | .51 – 1.65 |
| Mating Tab Width | 2.8 mm [ .11 in ] |
| Mating Tab Thickness | .51 mm [ .02 in ] |
Contact Features
| Connection Capacity | Single |
| Compatible With Wire & Cable Type | Discrete Wire |
| Terminal Orientation | Straight |
| Terminal Plating Material | Pre-Tin |
| Crimp Type | F-Crimp |
