3-770060-1PCB Terminals/PCB Pin PCB Terminal TE
Short Description:
PCB Pin PCB Terminal
3.18 mm [.125 in] PCB Hole
18 – 14 AWG
.8 – 2 mm² Wire
Through Hole – Solder
Pre-Tin Plating
Reel
Product Detail
Product Tags
TE Connectivity 3-770060-1 is a high-reliability vertical PCB terminal pin designed for space-constrained wire-to-board connections in industrial, automotive, and consumer electronics.
Key Specifications
Terminal Type：Female crimp receptacle (vertical mount)
Pin Diameter：0.64mm (0.025")
PCB Hole Size：0.7mm (0.028") recommended
Wire Range：18–14 AWG (1.0–2.08 mm²)
Material：Brass (tin-plated contacts)
Voltage Rating ：250V AC/DC (UL 1977 certified)3
Current Rating ：9A max @ 20°C
Temp Range：-40°C to +105°C
Mounting：Through-hole soldering
Data Overview
| PCB Terminal Type | PCB Pin |
| PCB Thickness (Recommended) | 1.57 mm [ .062 in ] |
| PCB Hole Diameter | 3.18 mm [ .125 in ] |
| Profile Height from PCB | 3.43 mm [ .137 in ] |
| Compatible Insulation Diameter (Max) | 3.81 mm [ .15 in ] |
Contact Features
| Terminal Features | Stud Hole |
| Contact Mating Area Plating Material Thickness | 5.08 µm [ 200 µin ] |
| Terminal Plating Finish | Bright |
| Terminal Plating Material | Pre-Tin |
| Terminal Orientation | Straight |
