Automotive Terminals 1703032-1:Receptacle Terminal, 20 – 18 AWG, .5 – .75 mm² Wire TE
Short Description:
Manufacturer:TE Connectivity
Product Category:Automotive Connectors
Product:Terminals
Gender:Receptacle (Female)
Mounting Style:Cable Mount / Free Hanging
Termination Style:Crimp
Contact Plating:Tin
Series:MQS
Contact Gender:Socket (Female)
Product Detail
Product Tags
Manufacturer:TE Connectivity
Part Number:1703032-1
Terminal Type:Receptacle (Female)
Compatible Wire:20–18 AWG / 0.5–0.75 mm²
Mating Pin Dimensions:Width: 0.63 mm (0.025 in), Thickness: 0.63 mm (0.025 in)
Current Rating :0–24 A (low power)
Product Line:MQS (Micro Quadlok System)
Material:Brass (base metal), Tin plating (contact surface)
Operating Temperature: -40°C to +125°C
Compliance:RoHS compliant
Typical Applications :Automotive wiring harnesses, ECU connections, sensor interface
Data Overview
| Terminal Type | Receptacle |
| Wire Size (AWG) | 20 – 18 |
| Wire Size (mm²) | .5 – .75 |
| Mating Tab Width | .63 mm [ .025 in ] |
| Contact Gender | Socket (Female) |
Contact Features
| Contact Fabrication | Stamped & Formed |
| Contact Size | .63mm |
| Crimp Type | F-Crimp |
| Typical Current Rating (A) | 7.5 |
| Interface Plating | Tin (Sn) |
